Nanoscale Characterization and Fabrication Lab (NCFL)

Nanoscale Characterization and Fabrication Lab (NCFL) at Virginia Tech provides shared-facility access for x-ray and synchrotron characterization, electron microscopy, nanofabrication and microfabrication, and surface and thin-film characterization. Registration, training, project review, fees, and current instrument availability may apply.

公开提供对外服务

4 项服务能力 9 条设备记录 核查于 2026年8月29日

公开描述的能力

Advanced characterization

X-ray and synchrotron characterization

Advanced characterization

Electron microscopy

Fabrication

Nanofabrication and microfabrication

Advanced characterization

Surface and thin-film characterization

了解设备

仪器型号

2 个型号示意图

CAD 示意图展示的是仪器型号。实际安装配置和当前可用性需向实验室确认。

技术清单

技术与设备

3 类设备

  • 微纳加工

    cleanroom process equipment

  • 显微与成像

    electron microscope

  • 显微与成像

    focused-ion-beam system

  • 表面分析

    surface analysis instrument

  • 显微与成像

    Additional official inventory includes JEOL IT-500HR and JSM-IT800 FEG SEMs, FEI Quanta 600 ESEM, JEOL JBX-8100FS EBL, AFM, triboindenter and specimen-preparation systems.

  • 显微与成像

    JEOL JEM 2100 analytical S/TEM provides STEM-EDS mapping to about 5 nm and imaging suited to polymeric and biological samples.

  • 显微与成像

    JEOL JEM ARM200F NEOARM aberration-corrected S/TEM uses a cold FEG at 80/200 kV, reaches 0.07 nm STEM HAADF resolution at 200 kV and carries dual 100 mm2 EDS detectors.

  • 表面分析

    PHI Quantera Hybrid XPS uses monochromatic Al K-alpha with 9-200 micrometre selectable beam, automated ion-milling depth profiling and a stage heated to 300 C.

  • 显微与成像

    Thermo Scientific Helios 5 UC combines SEM and FIB, with 0.6 nm electron resolution, 2.5 nm ion resolution, 500 V-30 kV operation, EDS/EBSD and 3D reconstruction workflows.

登记范围证据

  • ◇Network membership: NCFL is identified as a NanoEarth/NNCI facility..
  • ◇Facility: Virginia Tech identifies NCFL as a shared nanoscale characterization and fabrication laboratory..
  • ◇Official-source, facility-specific instrument evidence is available. Current configuration, availability, price, and project fit require confirmation.
